Hyperion X9 pro:
Innovation, power and versatility.

Maximum flexibility for your diagnoses. Hyperion X9 pro is fully configurable and its modular and scalable design makes it possible to transition from a basic to a more advanced version in an easy and cost-effective manner. An extraordinary platform that adapts to the needs of your dental practice thanks to the 2D PAN/CEPH sensor that can be easily relocated and to the reversible teleradiographic arm which can be installed on both sides. The most compact 3-in-1 hybrid system available on the market for high-quality 2D and 3D examinations.

  • Easily upgradable to every configuration
  • Reversible CEPH arm
  • Relocatable 2D sensor or two dedicated sensors for PAN and CEPH
  • The most compact 3-in-1 system
dott
Hyperion-X9-Pro-FOV

3D. SuperHD diagnosis.

MultiFOV and high resolution: wonderfull 3D images for all your radiology needs.

  • MultiFOV
  • 3 protocols each FOV
  • Extremely high resolution (up to 68μm)
  • Fast CB3D scan (up to 3.4s)
  • Low dose

2D. Capture every detail.

High-definition images, extremely sharp details, upgraded MultiPAN system for maximum results in every situation.

  • Dedicated and easily relocatable CMOS sensor
  • High orthogonality: reduces the overlapping of adjacent teeth and shows the structures to be examined in a clear and distinct manner
  • Wide range of focal layers
  • PiE (Panoramic Image Enhancer) filters
  • Segmentation of the areas of interest
  • QuickPAN feature to minimise scan times for fasterand more comfortable examinations

PANORAMIC EXAMINATIONS

HD panoramic X-ray and QuickPAN.
Full and reduced panoramic X-ray for children.
Orthogonal projection for the whole dentition (reduces the overlapping of dental crowns).
Segments of panoramic X-ray and dentition with optimised dedicated projections.
Bitewing exposures in 4 segments limited to the crowns, so as to highlight interproximal cavities.

TMJ EXAMINATIONS

(OPEN OR CLOSED MOUTH)

Latero-lateral projection of both TMJs.
Postero-anterior projection of both TMJs.
Latero-lateral projection from multiple angles (x3) of a single TMJ.
Postero-anterior projection from multiple angles (x3) of a single TMJ.

EXAMINATION OF THE MAXILLARY SINUSES

Frontal or left/right side view of the maxillary sinuses

HD MULTIPAN

Hyperion X9 pro provides clear and detailed panoramic images at all times. In one single scan, with the same exposure time and irradiated dose of a traditional panoramic x-ray, the unique MultiPAN feature generates 5 different focal layers to choose the one that best suits your diagnostic needs.

ADVANCED KINEMATICS

Hyperion X9 pro provides you with the most advanced imaging technology. It is indeed equipped with perfectly synchronised kinematics featuring one rotary movement and two simultaneous translatory movements that ensure constant magnification in all projections. The scans are always in focus thanks to the optimised focal trough which follows the patient’s morphology.

CEPH. Optimise every perspective.

High performance, ultrafast scans and a complete selection of cephalometric projections. Choose the examination that best suits your diagnostic requirements.

Hyperion X9 pro modular platform allows to add the teleradiography module at any time and with extreme ease. Its cephalometric arm is a true engineering masterpiece. Besides being the most compact system on the market, it is also reversible: it can be mounted either on the left or on the right, and, if space requirements change, Hyperion X9 pro CEPH changes with you. The relocatable latest-generation PAN/CEPH sensor, combined with an upgraded generator, guarantees excellent performance in any application. Select the exam that best suits your diagnostic needs choosing between ultrafast or high-quality scan.

ceph1

Teleradiographic Examinations

A highly synchronized kinematics structured around a rotary motion and two simultaneous translatory movements, for purposes of a constant enlargement of all the projections. The optimized focal layer follows the morphology of the patient, for the sake of images always in focus and a universe of high definition details.

  • Latero-lateral projection with selectable scan length
  • Paediatric latero-lateral projection with reduced height, short scan and low dose
  • FULL CEPH projection with reduced thyroid exposure and inclusion of skullcap in children
  • Antero-posterior or postero-anterior projection
  • Submento-vertex (SMV) projection, including Waters’ and reverse Towne views
  • Carpus projection

Smart Collimation

Thanks to the patented primary servo-controlled collimator, it possible to select the exact area to expose to the X-rays.

The patent-pending secondary collimator for teleradiography projections is integrated into the rotating module and allows for an easy access with minimum footprint.

Optimised work flow

Hyperion X9 pro optimises your work, adapts to your needs and allows to focus on what’s really important: your diagnoses.

iPAD CONTROL

Hyperion X9 pro is equipped with a user-friendly interface, also available in the iPad-specific application, for an easy and intuitive control. In few simple steps you can choose and set up the most appropriate exam based on the clinical and anatomical relevance.

PC INTERFACE

The multi-platform control panel gives you easy and immediate access to all the device features. The interface guides you step by step, from the exam selection to its preparation, with FOV guided positioning. The result is easier, faster and more effective examinations.

FULL-TOUCH 10’’ CONTROL PANEL

User-friendly graphics and direct controls make your work easier, providing patients with a more relaxing experience. Hyperion X9 pro is characterised by the simplicity of use and the rapidity of procedures, such as the possibility to choose predetermined programmes directly from the homepage. The control panel interface provides precise instructions on the patient’s positioning depending on the selected protocol.

GUIDED AND EFFECTIVE POSITIONING

The positioning is fast and accurate thanks to an alignment system with 4 laser beams projected directly on the patient’s face and to the state-of-theart ergonomic head support unit equipped with 7 fixing points for maximum stability during scanning. The Face to Face positioning guarantees maximum freedom of movement and the patient’s comfort.

SERVO-CONTROLLED SYSTEM

Through the Scout View system it is possible to centre the volume on the area of interest, while the patient can remain in the same comfortable position. From the PC, the operator can view the two images (sagittal and frontal) at very low irradiation and accurately modify the scanning area letting the equipment, supplied with servo-assisted movements, find the correct position. This procedure eliminates the risk of having to repeat the examination.

QUICK LOW-DOSE SCAN

Thanks to advanced QuickScan protocols, available for both 2D examinations and 3D  cquisitions, it is possible to obtain accurate images with lower doses as compared to a standard acquisition. These protocols are the ideal tool for post-surgery check-ups and for the identification of any  macrostructures (such as impacted teeth or dental agenesis).

Advanced, reliable, iRYS.

The best all-in-one software platform for 2D and 3D

mac
  • Multi-desktop 2D/3D
  • Implant simulation
  • Compatibility with third parties’ software
  • Sharing with 2D and 3D image viewer
  • iRYS Viewer for iPad

MyRay Hyperion X9 pro Brochure
