Durr X-ray Image Plate Scanners

VistaScan Mini View

The image plate scanner with a touchscreen for intraoral formats

The new VistaScan Mini View image plate scanner enables the intuitive, efficient, and time-saving digitisation of image plates. Amongst other things, its large touchscreen with its easy-to-use user interface contributes to this. Its compact size and integrated wireless functions make the device really flexible.

  • Top image quality
  • High-resolution touchscreen
  • ScanManager for optimum workflow
  • For all intraoral formats
  • Reliability thanks to internal memory
  • PC connection via WLAN/LAN
  • Standalone mode possible
vistascan-mini-view-durr_0

Specifications

Technical DataVistaScan Mini View
Screen4.3" touchscreen, 800 x 480 pixels, 16.7 million colours
Plate sizes0 to 4
Effective resolution (LP/mm, dpi)22, 1100
Theoretical resolution (LP/mm, dpi)40, 2000
Weight (kg)Approx. 7 kg
Dimensions (H x W x D in mm)275 x 226 x 243
Standby functionYes
InterfacesLAN, wireless

Video

Download

Durr Vista System Brochure

Plate Photos

VistaScan Mini Easy

Compact and easy

The VistaScan Mini Easy image plate scanner makes image plate diagnostics even faster for dentists. The compact device is particularly easy to use and requires a minimum of space – so that it can be installed in the treatment room. The advantage: X-ray and scanning directly at the chairside. The reusable VistaScan image plates are read out in top quality within seconds. There has never been a better time to change over to image plates.

  • Excellent image quality
  • Rapid image availability
  • Ideal chairside appliance
  • PC interface via USB or network
durr-dental-vistascan-mini-easy-500x500

Specifications

Technical DataVistaScan Mini Easy
Plate sizesS0; S2
Effective resolution (LP/mm, dpi)22; 1,100
Theoretical resolution (LP/mm, dpi)40; 2,000
Weight (kg)6.5
Dimensions (H x W x D mm)226 x 234 x 243
Standby functionYes
InterfacesUSB/Network

Download

Durr VistaScan Mini Easy Brochure

Plate Photos

VistaScan Combi View - efficiency without compromise

The image plate scanner with a touchscreen for all formats

The new VistaScan Combi View image plate scanner enables the intuitive, efficient and time-saving digitisation of image plates for both intraoral and extraoral formats. Amongst other things, its large touchscreen and easy-to-use user interface contribute to this. Thanks to the integrated wireless LAN functionality, the device is exceptionally flexible.

  • Highest image quality
  • High-resolution touchscreen
  • ScanManager for optimum surgery workflow
  • For all intraoral and extraoral formats
  • Table-mounted or (optional) wall-mounted
  • PC connection via WLAN/LAN
  • Work possible even without a PC
vistascan_combi_view

Specifications

Technical DataVistaScan Combi View
Screen4.3" touchscreen, 800 x 480 pixels, 16.7 million colours
Plate sizes0 to 4
Intraoral formats (cm)2 x 3 / 2 x 4 / 3 x 4 / 2.7 x 5.4 / 5.7 x 7.5
Panorama formats (cm)12.7 x 30.5 / 15 x 30
Ceph formats (cm)18 x 24 / 20 x 24 With VistaScan Omni View: 24 x 30
Eff ective resolution (lp/mm)22 (1100 dpi)
Theoretical resolution (lp/mm)40 (2000 dpi)
Greyscale (bits)16 (65,536)
Weight (kg)/mounting24/table-mounted; optionally, wall-mounted
Dimensions (H x W x D in mm)720 x 380 x 380
InterfacesLAN, Wireless

Video

Download

Durr VistaScan Combi Brochure

Plate Photos

VistaScan Mini Plus

The VistaScan Mini image plate scanner makes image plate diagnostics even faster for dentists. The compact device is particularly easy to use and requires a minimum of space – so that it can be installed in the treatment room.

The advantage:

X-ray and scanning directly at the chairside with full flexibility in the image formats. The re-usable VistaScan image plates are read out in top quality within seconds.There's never been a better time to change over to plates.

vistascan_mini_plus

Specifications

Technical dataVistaScan Mini Plus
DisplayYes
Plate sizes0 to 4
Effective resolution (LP/mm, dpi)22, 1100
Theoretical resolution (LP/mm, dpi)40, 2000
Weight (kg)6.5
Dimensions (H x W x D mm)226 x 234 x 243
Stand-by functionYes
InterfacesUSB/network

Video

Download

Durr Vista System Brochure

Plate Photos

Durr Dental Imaging Software

DBSWIN Imaging Software

Supports Microsoft Windows 7 -32 bit / -64 bit, Microsoft Windows 8 -64 bit, Microsoft Windows 10 -64 bit, Microsoft Windows Server 2012, Microsoft Server 2016.

  • 16-bit data with 65,536 grey-scale values for outstanding image quality
  • Caries and plaque diagnostics with VistaCam iX
  • Diagnostics supporting filter functions
  • Twain connection for OPGs
  • USB 3.0 support of all current devices
  • Creation of video clips
  • Status check assistant for VistaScan and VistaRay
  • SQL database, more performance and data security
  • Extensive import and export functions for exchanging data with colleagues, experts and clinics

VistaSoft

The completely newly developed VistaSoft imaging software provides a particularly efficient solution for the recording, display and editing of digital images. Improved workflows and self-explanatory icons allow the dentist even easier, quicker and more intuitive handling – and thus optimised surgery processes.

  • Ergonomic design with easy, quick and well thought-out workflows for efficient handling
  • Filter functions for supporting the diagnostics – e.g. for endo, caries, perio, etc.
  • Recording can be started and main functions called up with just one click
  • Saves time thanks to modern storage concept
  • Intuitive to use, among other things due to self-explanatory icons
  • 16-bit data with 65,536 grey scales for excellent image quality
  • Caries and plaque diagnostics with VistaCam iX & VistaCam iX HD
  • SQL database, greater performance and data security
  • Extensive import and export functions for data exchange with colleagues, appraisers and clinics

Dental Imaging iPad App

  • Calling up patients
  • Display of patient-specific X-ray and camera images
  • Display of layouts and groups
  • Free-hand sketches
  • Demo database with sample images
  • Offline database, for operation without active server interface

The imaging software from Dürr Dental has been used in dental surgeries around the world for more than 20 years and is now available in more than 20 languages. The imaging software offers the highest levels of operating comfort, compatibility and efficiency. All digital Dürr Dental diagnostics systems are controlled with the Dürr Dental imaging software. At the same time, you are supported by the integrated diagnostic tools. The software is compatible with all common diagnostics systems and practice management programs.

Durr Intraoral Cameras

VistaCam iX HD

Intraoral camera with interchangeable head system, autofocus and real HD image quality.

  • Brilliant HD image quality even in video mode
  • Autofocus for intraoral, extraoral and macro images
  • Software analysis to detect caries lesions and to visualise plaque by using the fluorescence effect (Proof interchangeable head)
  • Support for diagnosing approximal caries without exposure to radiation, thanks to infrared technology (Proxi interchangeable head)
vistacam_iX_HD

Specifications

Technical DataVistaCam iX HD
ConnectionsUSB 2.0 (USB 3.0 compatible)
Multiuser applicationPlug & Play
ActivationVia switch on hand piece (top or bottom, as desired)
Handpiece weight70 g
Handpiece length200 mm
Cable length2.5 m (optional extendable to 19,5 m)
Power supplyUSB (5V)
SensorHigh performance CMOS sensor
DriverUses standard Windows drivers, NO additional drivers needed
Resolution1280 pixel (H) x 1024 pixel (V)
Lighting2 LEDs, Proof (405 nm, violet), Proxi (850 nm, infrared)
Optical systemSeveral lenses and protective glass

Video

Download

Durr VistaCam iX HD Brochure

Camera Photos

VistaCam iX – one camera, many options

Thanks to the innovative interchangeable head, five options are immediately available:

  • Cam interchangeable head for intraoral images
  • Macro interchangeable head for magnifying images 120x
  • Proof interchangeable head makes caries and plaque visible on occlusal and smooth surfaces
  • Proxi interchangeable head helps diagnose approximal caries
  • Polymerisation interchangeable head for light hardening
vistacam-ix-cam_01

Specifications

Technical DataVistaCam iX PC Version
ConnectionsUSB 2.0
Freeze frame modulevia PC/Laptop
Multi-user applicationPlug&Play, cable can be connected to handpiece
Triggering/activationHandpiece (optional foot pedal)
Weight of handpiece (g)50 (without cable)
Handpiece length (mm)190
Power supply (5V)USB
Transmission path (2.5 m)USB 2.0, via cable

Video

Download

Durr VistaCam iX Brochure

Camera Photos
